AutoCAD for Beginners

Registration Closed

Course Information

Overview

نسعى في هذه الدورة الى تمكين المهندس من استخدام البرنامج بشكل محترف من خلال تفاعله مع مدرب مهندس ممارس للبرنامج في بيئة عمله و ان يسعى الطالب الى استخلاص ما هو مهم و اهم في خفايا البرنامج و نسعى الى تخريج مهندسين قادرين على اسقاط ما تعلموه في بيئة عملهم و تحسينها.
تعتمد الدورة على الامثلة العملية في كيفية إنشاء رسومات تفصيلية ثنائية الأبعاد، والتي تتضمن بشكل رئيسي المخططات والأقسام والارتفاعات المعمارية. و سيتعلم اخراج المخططات الهندسية (مخططات أفقية، عامودية، واجهات معمارية) بشكل فني.

Objectives

The main objective of this course is to provide the student an education in how to utilize computer software necessary to function as a CAD draftsperson. The student will learn how to manage numerous elements on the same drawing using layers, commands, and tools.

  • Enable participants to create detailed 2D drawings that mainly include architectural plans, sections, and elevations.
  • Learn the basic concepts and features of AutoCAD.
  • Familiarity with the program’s tools and techniques.
  • Acquisition of good skills in architectural design and drawing.
  • Acquiring the skill of dealing with measurement systems.
  • Enable participants to draw architectural and interior plans.
  • Enable the participants to draw the heights and sections and determine the dimensions.

Audience

Architectural engineering Students

Interior Design Students

Architects

Interior Designers

طلاب هندسة العمارة

طلاب التصميم الداخلي

مهندسي عمارة

مصممي الديكور الداخلي

Outline

  • Introduction
    • Installing the application on the Laptops
    • Learning about the user interface of AutoCAD, such as panels, ribbon, model space, etc
    • Learning basic drawing tools
  • Basic Drawing Skills
    • Navigating 2D Drawings, Drawing Lines and Rectangles, Canceling, Erasing, and Undoing
    • Understanding the concept of drawing a toolbar
    • Learning about line command, polyline command circle command and Arc command
    • Using Coordinate Systems
  • Using drawings Aid
    • Grid and Snap
    • Ortho and Polar Tracking
    • Polar Snap and Running Object Snaps
    • From Snap and Object Snap Tracking
  • Editing
    • Creating Selection Sets
    • Move and Copy, Rotate and Scale, and Working with Arrays
    • Trim and Extend, Lengthen and Stretch, Offset and Mirror
    • Grip Editing
  • Shaping Curves
    • Drawing and Editing Curved Polylines and Drawing Ellipses
    • Drawing and Editing Splines
    • Blending Between Objects with Splines
  • Controlling Object Visibility and Appearance:
    • Changing Object Properties
    • Organizing drawing objects in layers
    • Setting the Current Layer, Altering Objects’ Layer Assignments
    • Controlling Layer Visibility
    • Applying Line type, Assigning and Managing Layer Properties
  • Geometric Constructions:
    • Point commands
    • Ray commands
    • X-LINE commands
  • Hatching and Gradients:
    • • Specifying Hatch Areas
    • • Associating Hatches with Boundaries
    • • Hatching with Patterns, Hatching with Gradients
  • Creating and Editing Text:
    • • Creating Text Styles
    • • Transforming and Creating Text
    • • Writing and Formatting Paragraphs of Text using M-TEXT
    • • Editing Text
  • . Dimensioning:
    • Styling Dimensions
    • • Adding Dimensions
    • • Editing Dimensions
  • Working with Layouts and Annotative Objects:
    • Creating Annotative Styles and Objects
    • Creating Layouts and Adjusting Floating Viewports
    • Overriding Layer Properties in Layout Viewports, Drawing on Layouts
  • Printing and Plotting:
    • Configuring Output Devices
    • Creating Plot Style Tables
    • Using Plot Style Tables
